Good Quality 6 Axis Wireless Electric Encoder CNC Manual Pulse Generator E

Overview

Basic Info.

Model NO.	XWGP
Material	Plastic
Certification	ISO 9001:2008, ISO 9001:2000, GS, CE
Brand	Wixhc
Feature	Support 32 in The Same Room, No Interference
Wireless Distance	60 M
Support System	All CNC System
Spport	Maximum 6 Axis
Transport Package	Craton Box
Specification	small box 1kg
Trademark	Wixhc
Origin	China
HS Code	8538900000

Product Description

Product Description

Model: XWGP

·One pulse encoder, 100 pulses / turn ·An E-stop button ·One 6th gear axis selection switch and one 3rd gear magnification selection switch ·Six custom function button ·Enable button: press the enable button to output the encoder signal effectively. The receiver is equipped with an external antenna·Pulse specification: 5V/24V A.B.A\.B\ pulse·Display screen: display incremental coordinates and wireless signal strength·Maximum supported axes: 6 axes·Axis signal type:binary code/point-to-point signal·Multiplier signal type: binary code/point-to-point signal·Power supply: 2 AA batteries / 1 month+ battery life

Support system:

SIEMENS,MITSUBISHI,FANUC,FAGOR,Higerman,NUM, POUYUEN, SYNTEC and so on.

Basic parameters

Wireless transmission parameter
Communication channel	ISM 433M
power supply	Two alkaline AA batteries
Wireless transmission distance	Wireless transmission distance
DC electrical parameters
Handheld operating voltage	2.2V-3.3v(2 Section 5 alkaline battery)
Average operating current	<10 mA; low power , battery life is greater than 30 days
Receiver operating voltage	5V or 12V or 24V
Average operating current	Less than 260 mAh
Encoder pulse output parameter
Encoder	100 PPR 25PPR
Pulse signal type	5v differential signal or 12v non-differential signal
Pulse signal voltage	Support 5V,12V
Axis selection factor
Axis selection signal output mode	Point to point mode/ binary code
Magnification signal output method	Point to point mode/ binary code
Handwheel performance parameters
Transmit power	10DB
Receiving sensitivity	-98DB
Maximum supported axes	6-axis
Material	ABS PC alloy material

Company Information

Chengdu XinHeCheng technology co.,ltd is located in Chengdu Sichuan China.Our company integrates the development,

production and sale as a whole and providing motion control and wireless transimission solutions

XHC has always dovoted itself to develop wireless data transmission products with excellent -performance,low-cost,low-power,

which is widely used in cnc machine,helping numerous manufactors. XHC focused on motion control devevopment with cost effective and specialize.Provide perfect cnc product to custmomers .

Events

XHC released the china first wirleless handle for the engraving machine in year 2008. XHC released the china first wirleless tool setting gaguge in year 2009.XHC released the china first wirleless MPG in year 2010.XHC released the china first wirleless welding malipultor&positioner and rotator controller in year 2011.XHC released the MACH3 usb motion card in year 2013.XHC released the china most stable the fourth generation MACH3 usb motion card in year 2015.XHC released the fifth generation MACH3 usb motion card and mach3 Ethernet motion card in year 2016.

XHC have 4 Patents for utility modes; have 2 CE Certificates; have more than 20 prdoucts inlduing wireless MPG series,programmable mpg series,

welding controller series,motion card series.
